YOUR STREETS. YOUR PLAYGROUND.
Dominate the streets. Take command of supermoto tracks. Or simply put the pleasure back into your daily commute. The new DR-Z4SM provides a level of faithful performance and freedom that will boost your confidence and free you to ride unfettered. So, get out there. The streets are your playground to enjoy.
Features & Highlights
Colour Options
360° Viewer
Specifications
Engine
Type
Displacement
Bore x Stroke
Compression Ratio
Fuel System
Starter System
Lubrication System
Ignition System
4-stroke, single-cylinder, liquid-cooled DOHC
398cm3
90.0mm x 62.6mm
11.1 : 1
Fuel Injection
Electric
Dry Sump
Electric Ignition
Transmission
Transmission
5-speed constant mesh
Chassis
Suspension Front
Suspension Rear
Brake Front
Brake Rear
Tire Size Front
Tire Size Rear
Fuel Tank Capacity
Oil Capacity
Inverted telescopic, coil spring, oil damped
Link type, coil spring, oil damped
Disc
Disc
120/70R17M/C 58H, tube type
140/70R17M/C 66H, tube type
8.7 L
1.9 L
Dimensions
Overall length
Overall width
Overall height
Wheelbase
Seat Height
Ground Clearance
Curb mass
2,195 mm
775 mm
1,190 mm
1,465 mm
890 mm
260 mm
154 kg
Gallery
